Brogen LFP Yüksek Enerji Pil Paketi

  • Ultra-high energy density (155–165 Wh/kg) for extended driving range
  • Medium voltage LFP platform (96V–203V) for flexible EV integration
  • Lightweight high-capacity design for performance-oriented applications
  • IP68–IP69 protection for extreme environmental durability
  • 4000+ cycle life for long-term high-performance operation
Facebook
X
LinkedIn
E-posta

Brogen High Energy LFP Battery is a next-generation high-energy-density system designed for high-performance electric vehicles and long-range commercial mobility applications. Built on advanced Lithium Iron Phosphate (LFP) chemistry, it combines exceptional safety, thermal stability, and extended lifecycle performance.

With an energy density of 155–165 Wh/kg, this platform significantly improves driving range while maintaining structural efficiency and system reliability. Supporting a medium-voltage architecture from 96V to 203V, it offers flexible integration across multiple EV platforms, making it suitable for both commercial and performance-oriented vehicle designs.

The system is engineered for extreme environments, featuring IP68–IP69 protection, along with liquid cooling and heating capabilities to ensure stable operation from -30°C to 60°C. Its modular configuration (1P30S–1P63S) enables scalable deployment across different vehicle requirements.

With a high-cycle durability of 4000+ cycles, this battery is optimized for long-term high-intensity use, making it ideal for applications requiring extended range, reduced downtime, and superior energy efficiency.v

Ek bilgi

Pil Tipi

High Energy LFP

Model

OEKW173 / OEKW230 / OEKW304 Series

Uygulama

High-performance EVs, long-range vehicles

Sistem Enerjisi

23.4–35.3 kWh

Nominal Gerilim

96V–203V

Nominal Kapasite

NA

Konfigürasyon

1P30S–1P63S

Gerilim Platformu

Medium Voltage

Enerji Yoğunluğu

NA

Ağırlık (kg)

~200–320

Boyut L*W*H (mm)

820–1060 × 630 × 240–245

Koruma Derecesi

IP68–IP69

Soğutma Yöntemi

Sıvı Soğutma / Isıtma

Çalışma Sıcaklığı

-30°C ila 60°C

Ücretlendirme Oranı

1C

Çevrim Ömrü

≥4000 döngü

İletişim

CAN / RS485
