Brogen Electric Light Commercial Vehicle Motor 110kW Powertrain BG-Motor-OEYYH03A

The OEYYH01A is a high-torque traction motor designed for the demanding requirements of light trucks and light commercial EVs where axle integration places a premium on low-speed pulling force rather than top speed. Its 950 N·m peak torque at 358 V DC — a lower bus voltage than many comparable products — is achieved through a high peak current of 490 Arms, requiring robust thermal management via dual liquid/oil cooling with ≥15.0 L/min flow. Rated at 60 kW continuous / 110 kW peak, with a rated speed of 1,500 rpm and peak of 4,500 rpm, it suits e-axle configurations in 3.5–8 tonne GVW vehicles. The broad working voltage range of 200–550 V DC makes it compatible with 48 V stepping-up, 360 V mid-voltage, and 400 V+ battery architectures, maximising platform flexibility for vehicle integrators. A documented energy consumption of 0.42 Wh/km supports accurate range modelling for last-mile delivery fleet operators considering electrification.
